Boiler steel is used in a wide range of industrial processes, it is used in the power generation industry to heat water to produce steam, and in many large buildings to supply both hot water and heating.
In the food, chemical and pharmaceutical industries, it is used as part of the process to help transform raw materials into desired final products.
In the oil and gas industry, we use many boiler-quality steel plates, which are used in process modules, skids, and pressure vessels and heat exchangers in large downstream facilities.
Product Parameters
| Product Name | Boiler container plate |
| Type | Steel Sheet |
| Standard | JIS |
| Grade | Q235/A36/SS400/S235JR/ST37-2 |
| Place of Origin | China |
| – | Shandong |
| Skin Pass | Yes |
| Alloy Or Not | Non-Alloy |
| Delivery Time | 15-45 days |
| Thickness | 1.0-25mm |
| Application | Ship Plate, Container Plate, making pipes, making cold rolled steel products, Making Cold Rolled Steel Products |
| Width | 1000-1500mm |
| Length | Customers’ Request |
| Certificate | JIS |
| Tolerance | ±1% |
| Processing Service | Welding, Punching, Cutting, Bending, Decoiling |
Product Specifications
| Specifications（mm） | Thickness（mm） | Specifications（mm） | Thickness（mm） |
| 1260*2440 | 1.5 | 1260*6000 | 4. 5 |
| 1260*2440 | 2. 0 | 1260*6000 | 4. 75 |
| 1260*6000 | 1.8 | 1260*6000 | 4. 95 |
| 1260*6000 | 2. 0 | 1260*6000 | 5. 5 |
| 1260*6000 | 2. 5 | 1260*6000 | 5. 75 |
| 1260*6000 | 2. 75 | 1260*6000 | 5. 75 |
| 1260*6000 | 2. 95 | 1510*6000 | 8. 0 |
| 1260*6000 | 3. 5 | 1510*6000 | 10 |
| 1260*6000 | 3. 75 | 1510*6000 | 12 |
| 1260*6000 | 3. 95 | 1510*6000 | 15 |
The above are the general items, for the special types, we can also meet your needs.
| Product Details | Product Production | Product Warehouse |
 |
 |
 |
 |
 |
 |
Applications
Boiler vessel plates widely used in petroleum, chemical industry, power stations, boilers and other industries to make reactors, heat exchangers, separators, spherical tanks, oil and gas tanks, liquefied gas tanks, nuclear reactor pressure shells, boiler drums, liquefied petroleum gas bottles, Hydropower station high-pressure water pipes, turbine casings and other equipment and components
Project Cases
Additional Processing Technology
Boiler vessel plates can be treated with additional processes such as cutting, welding, drilling, labeling, oiling, and beveling.
Product Packaging
Product Transportation
